HTM55 Remote Tracked Mower

HTM55 RC Mower

HTM55 Remote Tracked Mower

The HTM55 high-performance remote controlled tracked flail mower is designed for demanding terrain, steep slopes, and professional vegetation management. Powered by a reliable YANMAR diesel engine and advanced hydraulic systems, it delivers exceptional durability, control, and productivity in extreme working conditions.

Ideal for roadside maintenance, embankments, forestry, solar farms, and hazardous or hard-to-reach areas, this machine ensures maximum safety and efficiency through remote operation and a low center of gravity.

Key Features

  • Heavy-duty YANMAR 3-cylinder diesel engine
  • Fully remote controlled operation for operator safety
  • Tracked undercarriage with high-traction rubber tracks
  • High-capacity hydraulic flail head
  • Designed for slopes up to 55°
  • Industrial-grade hydraulic and cooling systems
  • Compact dimensions with powerful output

Engine Specifications

  • Engine Manufacturer: YANMAR
  • Type: 4-cycle, inline, water-cooled diesel
  • Cylinders: 3
  • Max Power Output: 40 HP @ 2,600 RPM
  • Torque: 107.7 Nm
  • Fuel Type: Diesel
  • Fuel Tank Capacity: 28 liters
  • Combustion System: Direct Injection
  • Transmission: Fine-control hydrostatic
  • Cooling System: Heavy-duty 2-core water-cooled radiator
  • Self-Cleaning System: Manual standard, automatic optional

Hydraulic System

  • Pumps: 3 tandem piston pumps + 1 gear pump (P&G)
  • Drive Motors: High-torque piston motors (Poclain)
  • Flail Head Motor: High-speed motor (P&G)
  • Flail Head Circuit: Independent closed-circuit piston system
  • Track Drive Circuit: Dual independent closed-circuit piston systems
  • Auxiliary Motion Circuit: Open-circuit gear system
  • Hydraulic Oil Capacity: 23 liters (40 liters total system volume)
  • Attachment Lift Capacity: 750 kg

Tracks

  • Type: Rubber tracks with reinforced high-traction teeth
  • Maximum Working Angle: 55°

Remote Control System

  • Operating Range: Over 150 meters
  • Frequency: 434 MHz
  • Battery: Interchangeable, rechargeable batteries
  • Charging: Two batteries included, on-board machine charging
  • Controls: Proportional joysticks (standard)

Dimensions

  • Overall Width (with flail head): 1,500 mm
  • Overall Length (with flail head): 2,900 mm
  • Overall Height (with flail head): 1,300 mm

Weight

  • Machine Weight: 1,250 kg
  • Flail Head Weight: 200 kg

Performance

  • Maximum Slope Capability: Up to 55° in any direction

Safety Features

  • Slope warning alarm at 50°
  • Automatic engine shutdown at 55°

Applications

  • Steep slope mowing and embankment maintenance
  • Roadside and highway vegetation control
  • Forestry and land clearing
  • Utility corridors and solar farm maintenance
  • Hazardous or inaccessible terrain
